[1]陳寶玉,王正雄,楊濤,等.深層隧道排水系統中深隧泵站的設計與優化[J].中國給水排水,2021,37(4):62-66.
CHEN Bao-yu,WANG Zheng-xiong,YANG Tao,et al.Design and Optimization of the Deep Tunnel Pumping Station in Deep Tunnel Drainage System[J].China Water & Wastewater,2021,37(4):62-66.
點擊復制
CHEN Bao-yu,WANG Zheng-xiong,YANG Tao,et al.Design and Optimization of the Deep Tunnel Pumping Station in Deep Tunnel Drainage System[J].China Water & Wastewater,2021,37(4):62-66.
深層隧道排水系統中深隧泵站的設計與優化
中國給水排水[ISSN:1000-4062/CN:12-1073/TU] 卷: 第37卷 期數: 2021年第4期 頁碼: 62-66 欄目: 出版日期: 2021-02-17
- Title:
- Design and Optimization of the Deep Tunnel Pumping Station in Deep Tunnel Drainage System
- 關鍵詞:
- 深隧泵站(DTPS); CFD分析; 物理模型試驗
摘要:- 武漢市大東湖核心區污水傳輸系統工程采用深層隧道排水系統，隧道末端為北湖深隧泵站，其設計規模為100×104 m3/d，為壓力流泵站，地下深度為46.35 m，凈提升高度為16.1~22.4 m。泵組采用6臺離心泵（4用2備），單泵流量Q=2.79~3.87 m3/s，水泵揚程H=196.3~304.4 kPa。在北湖深隧泵站的設計過程中，采用了計算流體動力學（CFD）模擬分析、物理模型試驗、水錘分析及結構振動分析等方法，并根據分析結果對其設計方案進行了優化。
Abstract:- A deep tunnel drainage system was applied in the sewage transmission system project of Wuhan Dadonghu Core Area. The end of the tunnel is the Beihu deep tunnel pumping station, with a design capacity of 100×104 m3/d. It is a pressure flow pumping station with underground depth of 46.35 m and net lifting height of 16.1-22.4 m. Six centrifugal pumps, including 4 working pumps and 2 spare pumps, were applied, and the working range was Q=2.79-3.87 m3/s and H=196.3-304.4 kPa. In the design of the Beihu deep tunnel pumping station, the computational fluid dynamics (CFD) simulation analysis, physical model test, water hammer analysis and structural vibration analysis were used. According to the analysis results, the design scheme was optimized.
更新日期/Last Update: 2021-02-17
